40W Foldable All-in-One Solar Street Light with MPPT and IP67 Housing
Product Summary
The ML-PALM-40 is a 40W foldable all-in-one solar street light in the Palm Series, built by Cmoonlight for municipal and public facility road lighting. A 60W double-sided monocrystalline panel, a 40W Cree 5050 LED module rated at 200 lm/W, a 15Ah x 12.8V LiFePO4 battery and an MPPT controller are all housed in one die-cast aluminum body measuring 650 x 550 x 63 mm.
Because generation, storage and lighting sit inside a single foldable body, the luminaire needs no separate battery cabinet, no buried cable and no grid connection. Cmoonlight recommends a 4 m mounting height with 15-20 m spacing between poles, which fits road lighting projects where that installation geometry is specified.
Key Features
60W Double-Sided Panel
High-efficiency monocrystalline cells sit on both faces of the foldable body, lifting daily solar harvest within the same footprint.
40W Cree 5050 LED at 200 lm/W
US-made Cree LED chips deliver high luminous efficacy, so 40W is enough output for the recommended 4 m mounting height.
15Ah x 12.8V LiFePO4 Battery
Lithium iron phosphate chemistry supports 12 hours of nightly lighting and 3-5 continuous rainy days of autonomy.
MPPT Controller
Maximum power point tracking extracts more usable energy from the panel each day for steadier year-round operation.
Microwave Sensor Mode
Output runs at 100% when people approach and drops to 30% when the road is empty, which stretches nightly runtime.
IP67 and IK10 Protection
Die-cast aluminum housing with IP67 water resistance and an IK10 impact rating for exposed roadside installation.
Technical Specifications
Model
ML-PALM-40
Product Type
Foldable All-in-One Solar Street Light (Palm Series)
Solar Panel
60W double-sided monocrystalline
LED Power
40W
LED Chip
5050 Cree LED chip, 200 lm/W
Battery
LiFePO4 lithium, 15Ah x 12.8V
Controller
MPPT
Color Temperature
5000K standard, 3500-6000K customizable
Working Time
12 hours per night, 3-5 continuous rainy days
Control Mode
Light / Time / Microwave sensor control
Sensor Lighting Mode
100% when motion is detected, 30% when no motion
Recommended Installation Height
4 m
Recommended Installation Distance
15-20 m
Lamp Housing
Die-cast aluminum
Product Size
650 x 550 x 63 mm
Certifications
CB, CE, IK10, FCC, IP67, SGS, COC, NSS
Models and Options
The ML-PALM-40 is the 40W entry in the Palm Series. The series-level certificates issued for the Palm Series foldable all-in-one solar street light cover the 40W, 64W, 100W and 120W models, so one qualified platform can be specified across a project at different power levels.
Color temperature options - 3500K to 6000K on request
Materials and Structure
The lamp housing is die-cast aluminum for heat dissipation and mechanical strength on roadside poles. The double-sided monocrystalline panel folds around the integrated body, while the LiFePO4 battery, MPPT controller and 40W LED engine are enclosed in the same sealed assembly. This foldable all-in-one layout removes external wiring between components and keeps the shipping form compact compared with a split system.
ML-PALM-40 front view - 40W integrated LED engine in a die-cast aluminum housing.Palm Series ML-PALM-40 shown in a one-pole-with-two-lights arrangement.
Applications
The Palm Series is specified for municipal and public facility lighting, energy-saving programmes and road lighting. With a 4 m recommended mounting height and 15-20 m pole spacing, the ML-PALM-40 suits road lighting projects where that geometry is defined and no grid connection is available.
Municipal and public facility road lighting
Road lighting projects without grid access
Markets served include the Philippines, South America, Thailand, Malaysia, the Middle East and Africa
Customization
Color temperature can be set between 3500K and 6000K instead of the standard 5000K. Because the 40W, 64W, 100W and 120W Palm Series models share one certified platform, a project can combine power classes while keeping the same installation and control scheme. Our product photos show the light in both a single-luminaire layout and a one-pole-with-two-lights layout.
Frequently Asked Questions
What certifications does the ML-PALM-40 carry?
The light is listed with CB, CE, IK10, FCC, IP67, SGS, COC and NSS. Certificates on file include the TUV CB test certificate DE 2-034408, IP67 certificate CTE15GC-665IP, FCC CTE15GR-664F, CE CTE15GR-664E and the RoHS certificate CTE15GC-664R, all issued for the Palm Series 40W/64W/100W/120W range.
How high and how far apart should the pole be set?
Cmoonlight recommends a 4 m installation height with 15-20 m between poles.
How long does it run without sunlight?
The system is designed for 12 hours of operation per night and 3-5 continuous rainy days.
What battery and controller are used?
A 15Ah x 12.8V LiFePO4 lithium battery with an MPPT charge controller.
Can the color temperature be changed?
5000K is standard, and 3500-6000K can be customized on request.
How does microwave sensor control save energy?
The light runs at 100% brightness when motion is detected and falls to 30% when no motion is present.
